Model 700SA


Standard Features

  • Double column machine provides maximum capacity and rigidity.
  • Design utilizes linear bearings for high stiffness and smooth motion
  • Hydraulic lift of the saw head.
  • Saw up travel can be set to minimize distance between the blade and the top of the material.
  • Saw done travel can be set to allow notching of blocks.
  • Semi-automatic cut cycle.
  • Manual saw control, saw up, rapid saw down, saw cut, vise open and vise close.
  • Cutting feed rate hydraulically adjusted.
  • Load sensing valve stops the feed if the blade starts to overload, typical cutting structural shapes.
  • Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection.
  • Powered blade brush to remove cutting chips.
  • Manually adjusted vise.
  • Split vise design clamps material on both sides of the blade.
  • In-feed conveyor and material discharge conveyor.
  • Warnings for broken blade and doors open.
  •  Steel wheels with ductile iron hubs.
  • Blade guides are carbide faced with rollers to remove blade twist and dampen vibration.
  • Flood coolant system to both saw guides and a adjustable nozzle mounted on stationary vise, adjustable flow rates.
  • Direct blade drive using a planetary gearbox for a high efficiency drive.
  • Electric system uses only C.S.A./UL approved
  • components.
  • Premium quality bimetal band saw blade.
  • Instruction and parts manual.
