700CHFA
Standard Features
Material is fed via a shuttle vise
Stroke of vise is 25" (635 mm) with a length limit of 100" (2540 mm)
Length of cut accuracy to +/-.010" (.25 mm)
Length of cut repeatability +/-.010" (.1 mm)
Double column machine provides maximum capacity and rigidity
Design utilizes linear bearings for high stiffness and smooth motion
Hydraulic lift of the saw head
Saw up travel can be set to minimize distance between the blade and the top of the material
Saw down travel can be set to allow notching of blocks
Manual saw control, saw up, rapid saw down, saw cut
Cutting feed rate hydraulically adjusted
Load sensing valve which stops the feed if the blade starts to overload, typical when cutting the web of structural shapes
Full stroke hydraulic vises
Steel wheels with ductile iron hubs
Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
Flood coolant system to both saw guides with adjustable flow rates
Gear box designed for heavy duty band saw machines, high efficiency planetary drive, oil bath lubrication
Electric system uses only C.S.A./UL approved components and is electrically approved
Premium quality bimetal band saw blade
Instruction and parts manual
