700C

Standard Features

• Double column machine provides maximum capacity and rigidity.

• Design utilizes linear bearings for high stiffness and smooth motion

• Blade is canted at 4 degrees to aid in cutting structural steel profiles

• Hydraulic lift of the saw head.

• Saw up travel can be set to minimize distance between the blade and the top of the material.

• Semi-automatic cut cycle.

• Manual saw control, saw up, rapid saw down, saw cut, vise open and vise close.

• Cutting feed rate hydraulically adjusted.

• Load sensing valve stops the feed if the blade starts to overload, typical cutting structural shapes.

• Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection.

• Full stroke hydraulic vise.

• Powered blade brush to remove cutting chips.

• In-feed conveyor and material discharge table.

• Warnings for broken blade and doors open.

• Steel wheels with ductile iron hubs.

• Blade guides are carbide faced with rollers to remove blade twist and dampen vibration.

• Flood coolant system to both saw guides and a adjustable nozzle mounted on stationary vise, adjustable flow rates.

• Electric system uses only C.S.A./UL approved components.

• Premium quality bimetal band saw blade.

• Instruction and parts manual
