Model 475HFA

Standard Features

  • Material is fed via a shuttle vise
  • Stroke of vise is 24" (610 mm) with a length limit of 96" (2440 mm)
  • Length of cut accuracy to +/-.015" (.4 mm), repeatability +/-.005" (.1 mm)
  • Double columns provide maximum capacity and rigidity
  • Utilizes linear bearings for high stiffness & smooth motion
  • Saw up travel can be set to minimize distance between the blade and the top of the material
  • Saw down travel can be set to allow notching of blocks
  • Electronic variable speed drive, panel adjustable
  • Parts counter up to 9999
  • Fully-automatic cut cycle, consists of material advance, saw cut at end of cut the saw head will raise to top, repeat until parts counter decrements to 0
  • Manual saw control, saw up, rapid saw down, saw cut, vises open/close, shuttle advance/retract
  • Cutting feed rate hydraulically adjusted
  • Load sensing valve which stops the feed if the blade starts to overload, typical when cutting the web of structural shapes.
  • Full stroke hydraulic vises, with stationary vise retract of 1/2" to avoid interference with material.
  • Top vises with replaceable heavy flexible strip to clamp uneven material
  • Variable vise pressure.
  • Discharge table 37" wide by 24" long
  • Steel wheel with ductile iron hubs
  • Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
  • Flood coolant system to both saw guides and separate nozzle to allow coolant to center of cut with adjustable flow rates
  • High efficiency direct drive planetary gear drive system
  • Electric system uses only C.S.A./UL approved components and is electrically approved
  • Premium quality bimetal band saw blade
  • Instruction and parts manual
