475HDP

Standard Features

  • Double column machine provides maximumcapacity and rigidity

  • Design utilizes linear bearings for high stiffness and smooth motion

  • Electronic variable speed

  • Blade breakage and open door automatic shut off with alarm indicator

  • Hydraulic lift of the saw head

  • Saw up travel can be set to minimize distance between the blade and the top of the material

  • Saw down travel can be set to allow notching of blocks

  • Semi-automatic cut cycle

  • Manual saw control, saw up, rapid saw down, saw cut

  • Cutting feed rate hydraulically adjusted

  • Load sensing valve stops the feed if the blade starts to overload, typical cutting structural shapes

  • Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection

  • Power disconnect on machine

  • Blade guards

  • Powered blade brush to remove cutting chips

  • Hydraulic full stroke vise

  • Miter cuts up to 45 degrees by swiveling vise

  • Adjustable material length stop for repetitive cutting

  • Steel wheels

  • Blade guides are carbide faced with rollers to remove blade twist and dampen vibration

  • Flood coolant system to both saw guides with adjustable flow rates

  • Direct blade drive using a planetary gear box for  a high efficiency design

  • Electric system uses only C.S.A./UL approved components and is electrically approved

  • Premium quality bimetal band saw blade

  • Instruction and parts manual
