Model 400M

Standard Features

  • Scissor-type saw with heavy duty all welded design for rigidity and strength
  • Saw frame swings 45° forward, 60° to the rear allowing miter cutting with out swinging the material, indicating scale showing cut angle, hard stops at +45°, 0° and -60°
  • Hydraulic saw head lift and full stroke material clamp
  • Large base for stability with large coolant catch area
  • Pivot uses taper roller bearings for a highly rigid machine with smooth low friction movement
  • ·Conveniently located control station mounted on a swing-ing console for operator convenience
  • Cutting feed hydraulically regulated with feed rate scale
  • Magnetic motor starter with automatic shut off at the end of cut, motor thermal overload protection
  • Power disconnect on machine
  • Blade guards and fully enclosed drive belt guard
  • Powered blade brush to remove cutting chips
  • Adjustable material length stop for repetitive cutting
  • Ductile iron wheels
  • Blade guides are carbide faced with rollers to remove blade twist and dampen vibration, internal coolant channel to lubricate guides and direct coolant onto blade
  • Flood coolant system to both saw guides with adjustable flow rates
  • Gear box designed for heavy duty band saw machines, precision worm shaft on taper roller bearings and phos-phorous bronze worm gear set supported on sealed ball bearings, oil bath lubrication
  • Electric system uses only C.S.A./UL approved compo-nents and is electrically approved
  • Premium quality bimetal band saw blade
  • Instruction and parts manual
