Model 360HDP


Standard Features

  • Double column machine provides maximum capacity and rigidity
  • Design utilizes linear bearings for high stiffness and smooth motion
  • Hydraulic lift of the saw head
  • Saw up travel can be set to minimize distance between the blade and the top of the material
  • Saw down travel can be set to allow notching of blocks
  • Semi-automatic cut cycle
  • Manual saw control, saw up, rapid saw down, saw cut
  • Cutting feed rate hydraulically adjusted
  • Load sensing valve stops the feed if the blade starts to overload, typical cutting structural shapes
  • Magnetic motor starter with automatic shut off at the end of cut, motors thermal overload protection
  • Power disconnect on machine
  • Blade guards and fully enclosed drive belt guard
  • Powered blade brush to remove cutting chips
  • Full stroke hydraulic vise
  • Adjustable material length stop for repetitive cutting
  • Cast ductile iron wheel
  • Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
  • Flood coolant system to both saw guides with adjustable flow rates
  • Gear box designed for heavy duty band saw machines, precision machined worm shaft and phosphorous bronze worm gear set supported on taper roller bearings, oil bath lubrication
  • Electric system uses only C.S.A./UL approved components and is electrically approved
  • Premium quality bimetal band saw blade
  •  Instruction and parts manual
