Model 280S

Standard Features

  • Scissor-type saw with heavy duty, all-welded design for rigidity and strength
  • Miter cuts up to 45 degrees by swiveling vise
  • Large base for stability with large coolant catch area
  • Pivot uses tapered roller bearings for a highly rigid machine with smooth low friction movement
  • Conveniently located control station
  • Cutting feed hydraulically regulated with quick shut off to avoid valve adjustments
  • Magnetic motor starter with automatic shut off at the end of cut, motor thermal overload protection
  • Power disconnect on machine
  • Blade guards and fully enclosed drive belt guard
  • Powered blade brush to remove cutting chips
  • Quick adjusting material clamp
  • Material discharge table
  • Adjustable material length stop for repetitive cutting
  • Steel wheels
  • Blade guides are carbide faced with rollers to remove blade twist and dampen vibration
  • Flood coolant system to both saw guides with adjustable flow rates
  • Gear box designed for heavy duty band saw machines, precision worm shaft on taper roller bearings and phosphorous bronze worm gear set supported on sealed ball bearings, oil bath lubrication
  • All bearings are totally enclosed and lubricated for life ·
  • Electric system uses only C.S.A./UL approved components and is electrically approved.
  •  Premium quality bimetal band
